After downloading US census data, you often need to reformat it before using it. It’s quite common that you download files where the population is broken down by gender and age, and you need to aggregate the data to get a total or divide a particular characteristic to get a percent total. This is pretty straightforward if you’re working with decennial census data, but data from the American Community Survey (ACS) is a little trickier to deal with since you’re working with estimates that have a margin of error. When creating new data, you also have to calculate what the margin of error is for your derived numbers. I’ll walk through some examples of how you would do this in a spreadsheet (the formulas below will work in either Excel or Calc).

Creating an Aggregate

We’ll use the following data in our example:

We have the total population of people three years and older who are enrolled in school, and a breakdown of this population enrolled in grades 1 through 4 and grades 5 through 8 in a few counties in New York, with margins of error for each data point. Our data is from the 3 year averaged 2005-2007 American Community Survey.

Let’s say we want to create a total for students who are enrolled in grades 1 through 8 for each county. We create a new column and sum the estimates for each county with the formula e3+g3, or sum(e3:g3).

To calculate a margin or error (MOE) for our grade 1 to 8 data, first we have to use the find and replace command to get rid of the “+/-” signs in the MOE column, so our spreadsheet will treat our values as numbers and not text (this is an issue if you downloaded the data as an Excel file - if you download a txt file the +/- is not included). Depending on the dataset you’re working with, you may also need to replace dashes, which represent data that was null or not estimated.

Once the data is cleaned up, we can insert a new column with this formula:

=SQRT((F3^2)+(H3^2))

This calculates our new margin of error by squaring the moes for each of our data points, summing the results together, and taking the square root of that sum. In other words,

=SQRT((MOE1^2)+(MOE2^2))

Once that’s done, you may want to round the new MOE to a whole number.

Creating a Percent Total

Let’s calculate the percentage of the population 3 years and older enrolled in school that are in grades 1 through 8. Based on what we have thus far (I hid the columns E,F,G, and H for grades 1-4 and 5-8 in this screenshot, as we don’t need them):

We insert a new column where we divide our subgroup by the total, as you would expect - I3/C3. In the next column we insert the following formula to create a MOE for our new percent total:

=(SQRT((J3^2)-((K3^2)*(D3^2))))/C3

This one’s a little weightier than our last formula. We’re taking the square of our percent total (K3) and the square of the MOE of the total population (D3), multiplying them together, then subtracting that number from the square of the MOE of our subgroup (J3). Then we take the square root of the whole thing, then divide it by our total population (C3). If you’re saying - HUH? Maybe this is clearer:

=(SQRT((MOEsubset^2)-((PercentTotal^2)*(MOEtotalpop^2))))/TotalPop

Finally, we have something like this:

Based on our data, we can say things like “There were approximately 30,556 students enrolled in 1st through 8th grade per year in Dutchess County, NY between 2005 and 2007, plus or minus 1,184 students. An estimated 37% of the population enrolled in school in the county was in the 1st through 8th grade, plus or minus 1%.” The ACS estimates have a 90% confidence interval.

Wrap Up

In this example we worked with aggregating and calculating percentages based on characteristics. We could also use these same formulas to aggregate data by geography, if we wanted to add the characteristics for all the counties together.

For the full documentation on working with ACS data, take a look at the appendix in the Census’ ACS Compass Guide, What General Data Users Need to Know. It provides you with the formulas in their proper statistical notation (for those of you more mathematically inclined than I) and includes formulas for calculating other kinds of numbers, such as ratios and percent change. It does provide you with worked-through examples, but not with spreadsheet formulas. I used their examples when I created formulas the first time around, so I could compare my formula results to their examples to insure that I was getting it right. I’d strongly recommend doing that before you start plugging away with your own data - one misplaced parentheses and you could end up with a different (and incorrect) result.

The US Census Bureau has begun releasing data for the 2007 Economic Census. The bureau conducts the survey of businesses every five years - all medium to large size businesses and multi-part businesses are counted, samples are taken for smaller businesses, and various administrative records are used to calculate businesses with no employees (i.e. freelancers). All businesses are categorized hierarchically by North American Industrial Classification System (NAICS) codes and the data is reported by industry and geography. The number of establishments, employees, payroll, and sales are counted for the nation, states, counties, metro areas, places, and zip codes.

At this point national industry totals for the broadest categories of NAICS are available, as are preliminary numbers for the most specific NAICS categories (six digit) at the national level. Data for smaller geographic areas will be released between October 2009 and August 2010.

The biggest change from the 2002 Economic Census is the delivery method for the data. There will be no more 90 page pdf files or HTML tables that drill down six levels. All of the data will be released via the American Factfinder only. Other changes include the addition of some new geography (CDPs with at least 5000 people), new metro area definitions, and the revised 2007 definitions for NAICS which include small changes to the Finance, Insurance, Real Estate, Professional Services, and Administrative Services categories.

Additional changes for 2007, the data release schedule, NAICS codes, and methodology docs are all available at the 2007 Economic Census homepage within the Census Bureau’s website.

All of the data is aggregated by industry and geography - you cannot get lists of businesses with names and addresses as this information is kept confidential. Furthermore, to maintain confidentiality, if one company controls a large share of the market for a specific sector within a specific geographic area, or if there few businesses within a sector in a specific geographic area, much of the data (with the exception of the number of businesses) remains classified (marked with a D for disclosure). Oftentimes this means that data for industries within small areas (big box retail in a small town) and data for industries with few establishments in an area (mining establishments in New York City) are hidden. The smaller the geography, the more likely it is that the data will not be disclosed. This becomes a technical issue if you want / need to move this data into a database, as these pesky disclosure notes are stored in the same columns as the data and prevent you for designating the fields as numeric.

Given the delay between the time the data is collected and the time it is released, it isn’t particularly helpful for analyzing our current economic climate, but it does provide a snapshot of the way the US economy looked at that moment, and is useful in understanding how the economy is evolving. Be aware that when making comparisons to past data, you have to correct for changes in geography and NAICS definitions. The differences between 2002 and 2007 are not too great, but more adjustments are necessary as you go further back in time. The Bureau provides data back to 1997 through the American Factfinder and some data from 1992 on an older page. If you need to go back further, you’ll be entering the realm of (gasp!) CD-ROMs or the paper reports.

In my previous post I gave an overview of how to create a shapefile from scratch, where we created a point layer to identify places and neighborhoods in NYC. In this post, I’ll pick up where we left off.

Whenever you create new features in a shapefile, ArcGIS automatically adds a couple of fields, including an auto-number ID field that uniquely identifies each feature. This was sufficient for our example as the 291 place names we were working with do not have a standard ID number that represents them. If we were creating features that did have a recognized ID number or code, we certainly would want to add an additional field to hold that number. This would allow us to share and relate our data to other datasets that use that conventional ID. For example, if we had a layer with the 50 states, we would want to have a FIPS number or the two digit postal code for each state in the attribute table, so we could relate our states feature to the zillions of other state-based data tables out there that also use these codes.

It’s also helpful to add other identifiers to relate our place names to some larger geographic area. Why? Let’s say we want to filter our neighborhoods by borough - perhaps we just want to label neighborhoods in Manhattan or calculate distances only between places that appear in the Bronx. It would be useful to have a borough code or some other code associated with each of our place names for running queries.

As it turns out, the City of New York does use a standardized system of three digit codes to identify all boroughs and community districts in the city. In our example, the code for Manhattan Community District 12, which contains Inwood and Washington Heights, is 112. The first digit identifies the borugh and the second two digits identify the district. It would be a good idea to assign each of our neighborhoods this district code, so we could filter our features by either borough or district.

When we create each feature, we could manually type in the code in it’s own field just like we added the neighborhood names, but that would be rather tedious - and unnecessary. A better choice would be to do a spatial join. Whereas a “regular” join allows us to join attribute tables based on a common ID field, a spatial join allows us to assign attributes to one layer based on their geographical relationship to another layer.

In the Table of Contents, right click on the neighborhoods layer and choose Joins and Relates - Joins. We’ll get the familiar Join dialog box. However, if you hit the first drop down box that says Join Attributes From a Table and choose Join Data Based on Spatial Location, we’ll get the options for doing a spatial join. Choose the community districts as the layer to join to the neighborhoods, and since we’re joining points to polygons we’ll choose parameters that are relevant for relating these two features. In this case, give each point (neighborhood / place) the attributes of the polygons (districts) that it falls inside. ArcGIS will create a new point layer with the joined fields when you hit OK. Open the attribute table of the new point layer, and you’ll see the additional fields, including the community district numbers. You’ll also get some rather useless fields from the district layer, like the length and area of each district, which you can safely delete.

So instead of tediously entering these numbers by hand for each neighborhood, we simply run the spatial join process once (after we’ve finished adding the points for all 291 neighborhoods) and the IDs are automatically added.

I’m working with a grad student who needs to create a new shapefile from scratch, and thought I’d turn the instructions for doing this in ArcGIS into a tutorial / post for creating new point layers. The idea in this example is to create a point layer that shows the relative center of 291 neighborhoods in New York City. Since many of these neighborhoods are place names without finite boundaries, we’ll have to use various sources (NYC Planning map and Rand McNally street maps) to pinpoint the relative center of each neighborhood.

These points will be used for labeling each neighborhood. In this case, creating a new, georeferenced layer is preferable to creating 291 text labels on a map that are not tied to geography in any way.

• The first step is to download some layers from the NYC Department of Planning to use for reference, such as a layer for boroughs and community districts. Community districts are used by the city to approximate neighborhoods. Many of the neighborhoods that we are trying to plot are, in many cases, smaller areas or places within these boundaries.

• Next, open ArcCatalog and create a folder to store the data. Then, right click on the folder in the table of contents and select New - Shapefile. In the Create New Shapefile window, we give the shapefile a name, select Point as the feature type, and hit Edit to change the
  coordinate system. In the Spatial Reference Properties menu, we’ll import a coordinate system from one of the files we downloaded from NYC Planning, which uses New York State Plane for Long Island. Click OK and OK again, and we’ll have a new shapefile.

• Right now, our new shapefile isn’t very exciting because it’s empty - you can preview it in the catalog to see for yourself. If you preview the table, you’ll see that Arc created three fields - FID, Shape, and ID, which it will automatically fill in when we start creating features. Before we do that, we’ll have to add an additional column to store the name of the neighborhood. To do that, open ArcMap and add the neighborhood layer to the map. Then, right click on the layer in the Table of Contents and open the attribute table. Hit the Options button and choose Add Field. In the Add Field menu, name the new field, choose Text as the type, and change the length to 80 (in case we have some neighborhoods with long names). Hit OK, and you’ll have a new field.

• Let’s add our reference layers next. Hit the Add Data button (or File - Add Data), and add the borough boundaries and community districts (if you don’t see anything after you add them, right click on one of these layers and choose Zoom to Layer). Go into the symbology tab for each layer and change their display to make the areas appear more distinctive. Make sure your neighborhood layer is on top of your other layers.

• Now it’s time to start plotting neighborhoods. Go to the Selection menu - Set selectable Layers, and turn off all the layers except the neighborhood layer. Then, use the dropdown on the Editor Toolbar and Select Start Editing (if you don’t see the Editor Toolbar, make sure it’s activated by going to View - Toolbars and select it). On the Editor Toolbar, make sure the Create New Feature task is activated and that the target layer is the neighborhood layer, and not any of the reference layers. Zoom in to the top of Manhattan. With the Pencil tool selected in the toolbar, and using your sources (NYC planning map, Rand McNally street map, whatever), click on the map to approximate where the center of the Inwood neighborhood would be. A blue dot should appear on the map. Then right-click on the neighborhoods layer in the Table of Contents and open the attributes table. You’ll see a brand new record for your new dot. Click in the empty field for Name, type in the name of the neighborhood, and press enter.

• That’s the process! Next, locate the area for Washington Heights and click on the map to create the point for that neighborhood. The new dot will appear hi-lighted, while the previous dot for Inwood will now appear as a regular point symbol. Now it’s just a matter of plugging away. Make sure to occasionally save your edits by clicking Editor and choosing Save Edits. If you make a mistake, you can delete a feature by selecting the Select Feature tool in the regular tool bar (white arrow with a blue and white feature box next to it), select the particular point, and hit the delete key. If you’re having trouble pinpointing the right location for the neighborhood, try downloading additional reference layers to guide you. The NYC DOITT also has a page with GIS layers for the city with features like parks and streets that may be helpful. When you’re finished editing, choose Stop Editing under the Editor Toolbar.

• The ultimate goal of this exercise was to get neighborhood labels to appear without the actual point. To accomplish this, change the point symbol for the neighborhood to nothing by going into the Symbology tab for the layer and reducing the fill to no color, the outline to nothing, and the size to zero. Then open the Labels tab under the Properties menu, turn labels on using the name field as the label field, select Placement Properties and choose the setting to place the labels on top of the point, hit ok, and voila! Perfectly centered neighborhood names that are part of a georeferenced layer.

This covers the basics. In the next post, I’ll go a little further and discuss adding additional fields to the new file, without having to type them in manually.
